SRAM FPGAs
Tiny, Low Cost SRAM Reprogrammable FPGAs with Open Source Tools
Small footprint, Low-power, Reconfigurable
The PolarPro 3 is a reconfigurable, SRAM based FPGA designed for mobile device connectivity. A single device with 1019 Logic Cells and 73K bits of RAM is available in 0.4mm WLCSP and VFBGA packages. The PolarPro 3 is supported by both the QuickWorks design environment and by Open-Source FPGA tools.
Features
Reconfigurable SRAM Technology
Supports last minute production changes
Low Power
55uA standby power ideal for battery-powered applications
Small Footprint
As small as 2.09mm x 2.54mm in the WLCSP package
Benefits
Simplified Supply Chain
Program product options and versions at shipment minimizing inventory costs
Fast Time-to-Market
Implement new product ideas without long cycle times
Battery Life
Extend battery life and keep mobile users on the go
QuickLogic SRAM Reprogrammable FPGAs for Consumer IoT and Industrial IoT
Product Videos
PolarPro 3 Design Tool Installation
PolarPro 3 Example Counter Design through Tool Flow
PolarPro 3
PolarPro 3 was specifically architected to meet the increasingly complex needs of mobile device OEMs. With special attention paid to efficient logic cell utilization, smallest size, and lowest power consumption during the design process, PolarPro 3 is the ideal solution for OEMs who require a configurable logic solution for their application.
| Features | 1,019 Logic Cells | |
|---|---|---|
| Max Gates | 175,000 | |
| Logic Cells | 1019 | |
| 8K RAM Modules (9216 bits) | 8 | |
| FIFO Controllers | 8 | |
| RAM bits | 73,728 | |
| Max I/O per Package | 30-ball WLCSP (0.4 mm pitch) | 18 |
| 64-ball VFBGA (0.4 mm pitch) | 46 | |
